ERTi-1 Titanium Welding Wire

Titanium Welding Wire.ERTi-1,ERTi-2,ERTi-5, ERTi-7, ERTi-9,ERTi-23, Standard AWS A5.16, U Will Get What U Want From Us - details see: https://www.machineto.com/erti-1-titanium-welding-wire-10283273

Place of Origin:Shaanxi China (Mainland)	Brand Name:LH	Model Number:LHTi005	Material:ERTi-1,ERTi-2,ERTI-3,ERTi-4,ERTi-5, ERTi-7, ERTi-9,ERTi-23
Standard:AWS A5.16	Application:Oil And Chemicals,Power Generation,Marine Corrosion, Medical And Sport	Characteristic 1:Superior corrosion resistance	Characteristic 2:Lower life-cycle costs
Characteristic 3:Longer service life	Characteristic 4:Lower maintenance and repair costs	Characteristic 5:More lighter than other metals	Characteristic 6:Good miscibility with blood
Characteristic 7:Higher strength to weight ratio

contact supplier for ERTi-1 Titanium Welding Wire

Titanium welding wire,Titanium wire

1. Titanium Wires Dimension Tolerance

Diameter	0.1-0.3mm	0.3-0.8mm	0.8-2.0mm	2.0-6.0mm
Tolerance	+/- 0.025	+/-0.04	+/-0.05	+/-0.10
Length	200-500mm	500-1000mm	1000-2000mm	&2000mm
Tolerance	+/-1.0	+/-1.5	+/-2.0	+/-2.5

2. Available Diameter, Type & Packing

Size (mm)	Dia 0.8	Dia 1.0	Dia 1.2	Dia 1.6	Dia 2.0	Dia 2.4	Dia 3.0	Dia 3.2	Dia 4.0	Dia 6.0
Size (inch)	0.031"	0.039"	0.047"	0.062"	0.079"	0.093"	0.12"	0.125"	0.16"	0.24"
Straight			OK	OK	OK	OK	OK	OK	OK	OK
Spool	OK	OK	OK	OK	OK	OK
Coil			OK	OK	OK	OK	OK	OK	OK	OK

3. Welding Products List

AWS Classification	CHEMICAL SPECIFICATIONS									MECHANICAL Property
AWS A5.16	UNS No	ASTM B348	C	O	N	H	I	Al	V	Tensile Strength	%EI.
ERTi 1	R50100	GR 1	0.03	0.03-0.10	0.012	0.005	0.08			180	37
ERTi 2	R50120	GR 2	0.03	0.08-0.16	0.015	0.008	0.12			240	28
ERTi 3	R50125	GR 3	0.03	0.13-0.20	0.02	0.008	0.16			340	26
ERTi 4	R50130	GR 4	0.03	0.18-0.32	0.025	0.008	0.25			550	23
ERTi 5	R56400	GR 5	0.03	0.12-0.20	0.030	0.015	0.22	5.5-6.7	3.5-4.5	1000	18
ERTi 7	R52401	GR 7	0.03	0.08-0.16	0.015	0.008	0.12			340
ERTi 9	R56320	GR 9	0.03	0.08-0.16	0.020	0.008	0.25			615	17
ERTi 23	R56408	GR5-ELI	0.03	0.03-0.11	0.012	0.005	0.20	5.5-6.5	3.5-4.5	1000	18
