1.Energy Saving Wet Ball Mill price, 2.ISO9001:2000;, 3.ball mill saving energy about 30%, 4.high capacity ball mill - details see: https://www.machineto.com/energy-saving-wet-ball-mill-price-in-china-10314194

1.Large application range, simple structure and convenient maintenance;
2.Large capacity and continuous work are very obvious;
3.Barrel lining and grinding media can apply various abrasive materials;
4.Installation and adjustment are very convenient and easy to be operated.

Energy-Saving Wet Ball Mill Application:

Energy-Saving Wet Ball Mill is generally used to grind material 1/4 inch and finer, down to the particle size of 20 to 75 microns. To achieve a reasonable efficiency with ball mills, they must be operated in a closed system, with oversize material continuously being recirculated back into the mill to be reduced.Various classifiers, such as screens, spiral classifiers, cyclones and air classifiers are used for classifying the discharge from ball mills. Ball mill is an efficient tool for grinding many materials into fine powder. The ball mill is used to grind many kinds of mine and other materials, or to select the mine. It is widely used in building material, chemical industry, etc. There are two ways of grinding: the dry process and the wet process. It can be divided into tabular type and flowing type according to different forms of discharging material.

Wet Ball Mill Working Principle:

The Energy-Saving Wet Ball Mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.

No	Model	Dia. Of the Shell(mm)	Lenght(mm)	Capacity(m3)	Max Loading Ore Steel Ball(t)	Motor Power (kw)	Overall size(L×W×H)	Weight(t)
1	1500×1500	1500	1500	2.2	5	37		13.7
2	2100×3000	2100	3000	9	20	210		50.6
3	2400×3000	2400	3000	12	3.5-25	380	9.3×5.6×4.45	57.36
4	2700×3600	2700	3600	18	40	530		77
5	3200×3100	3200	3100	21.9	47	800	8.06×6.4×5.5	104
6	4000×6700	4000	6700	75.95	19.6-139.8	1350	15.6×8.43×7.1	235.9
