1.Stainless steel, 2.Use:pharmaceutical,Laboratory,medical,drink,oral liquid, 3.Capacity:200L/H, laboratory water distiller - details see: https://www.machineto.com/electrical-laboratory-water-distiller-10306441

200L Electrical laboratory water distiller

1.Made from quality stainless steel.

2. High-effect Electrical water distiller DGJZZ-200 is used for pharmaceutical preparations and Lab distilled water, electric distillation water heater
3.Distilled water production Outflow Capacity: 50L/H,100L/H,150L/H,200L/H.

4.Saving steam and water, Water quality high,water fast.

5. Automatic descaling when 1mm thickness,Extend the service life

Electrical High-effect water distiller machine

Product Features

1- Environmental Protection

Energy-saving,high efficiency, pollution-free.

2-Long life

Automatic descaling,extended service life, ensure the water quality and quantity

3-Saving Steam

Steam consumption 102% under air pressure in the 0.1-0.25Mpa, 18% lower than the Tower-type distilled water machine.

4-Saving Water

Good saving water performance, cooling water saving water 60% lower than tower-type water distiller machine.

5-Saving Equipment

1) The equipment could directly use the natural water or city water,do not need pure water or reverse osmosis water.

2) Compared with Multi-effect water distiller machine,this equipment could save the early reverse osmosis equipment (Electrodialysis), mixed bed, which saves investment costs.

3)Electrical High-effect water distiller also can save the boiler equipment, and replace the boiler to produce steam power.

6-PH value Adjustable

Using Temperature adjustment method to adjust the distilled water carbon dioxide and ammonia content, reach to adjust the PH of distilled water, adjusting value from 5-7 random adjustable.

7-Output water High quality

The produced water quality conductivity could meet GB<=2us/cm.

Working Principle

1. Access to the boiler steam,steam pass through the vapor-liquid separator, the water and impurity was discharged from the sewage valve, the pure steam enter into the evaporating pipe, make inside the distiller once distilled water evaporated into steam,steam pass through the membrane filter into the spiral condenser and cooled into distilled water, then outflow from exit.

2.Steam in evaporation tube after release heat, self-liquefaction, pass the resistance steam valve went into the water bucket, the water will be injected into evaporation boiler as add water.

Usage

The equipment apply to large, medium and small pharmaceutical companies, such as oral liquid, eye drops water and so on, all levels of hospital preparation room, chemical research institutes.

Product Model No.

50L/H,100L/H,150L/H,200L/H.

,

.
