DPP-100 truck mounted drilling rig

It is suitable In liquids and natural gas holes drilling. - details see: https://www.machineto.com/dpp-100-truck-mounted-drilling-rig-10313131

Condition:New	Type:Rotary Drilling Rig,Drilling Rig	Place of Origin:China (Mainland)	Model Number:DPP-100
Usage:Water Well	Application:liquid

contact supplier for DPP-100 truck mounted drilling rig

. Application Range

(1)Exploration in shallow holes of mine and seismic exploration drilling.
(2)In liquids and natural gas holes drilling.
(3)Construction shot drilling.
(4)Geological exploration and shallow water well drilling.

2.Main Features
(1)Having hydraulic pressure and high ability of pulling down and pulling up. The operation is easy and the labor intensity is reduced.
(2) Being provided planetary hoisting the operations are easy, safety and reliable.
(3) The mud pump is high self-adsorb ability and can be regulated 10 kind flows.
(4) The water cock is small volume, light in weight and better seal.
(5) The driver rod has high rigidity, weightier, being pressure by self-weight.
(6) Having Hydraulic mast, convenient in operation.

3.Technical Specifications of drill

Specifications \ model		DPP100-3 series	DPP100-5series
max drilling depth (m)	7 3/4" bit(200mm)	70	70
max drilling depth (m)	5 3/4" bit(150mm)	100	100
Hex Kelly bar(substense×longth)(mm)		75×5500	75×5500
rod dia (mm)		50	50
max feeding/pulling capacity(KN)		30/50	48/70
feeding stroke (mm)		450	1200
traveling stroke (mm)			450
single wire lifting capacity of main/auxiliary hoist(KN)		12.5 /10	12.5 /10
Max working pressure of water pump(MPa)		2	2
Max displacement of water pump (L/min)		450	450
Max pressure of hydrualic system(MPa)		8	8

4.Specifications of truck

Drill model	Chassis model	Engine model	Overall dimension L×B×H (mm)	Total weight(Kg)	Power(KW)	rotary table spindle speed (r/min)	fuel	Passenger
BT5074TZJ DPP100-3B	EQ1093FJ	EQ6100-1	9100×2470×3400	7300	99	55,102,176	gasoline	3
BT5083TZJ DPP100-3A	CA1097K2	CA6DE2-16	9100×2460×3350	8070	117	81,135,226	diesel oil	3
BT5107TZJ DPP100-5F	CA1140P1K2L1RA	CA6DE2-18 CA6DF2D-17	9035×2470×3730	9650	132 125	65,114,192	diesel oil	6
