Dongfeng 6*4 Water Truck 25-30m3

Dongfeng 8*4 Water Truck 25-30m3, 1.EU standard, 2.Chassis can be choosen, 3.sprinkler width >16m - details see: https://www.machineto.com/dongfeng-6-4-water-truck-25-30m3-10112689

Drive Wheel:6x4	Fuel:Diesel	Transmission Type:Manual	Condition:New
Sprinkling Area (m):> 16 m	Emission Standard:Euro 3	Engine Capacity:> 8L	Tank Volume:15001 - 30000L
Brand Name:hys	Place of Origin:Hebei China (Mainland)	Model Number:hys	Certification:3c
Warranty:one year	After-sales Service Provided:Engineers available to service machinery overseas	Overall dimension (mm):1199024953560	Chassis type:EQ1290WJ
Cubage(T):26-30

Product	Dongfeng front four rear eight watering truck
Chassis type	EQ1290WJ
Cubage(T)	26-30
Parameters	Overall dimension length/width/height (mm)	11990×2495×3560
	Total Mass(kg)	29490
	Payload(kg)	14800
	Kerb Mass(kg)	14495
	Approach angle/ Departure angle(mm)	32/15
	Front suspension/rear suspension(mm)	1250/3240
	Fuel Type	diesel
	Fuel Consumption/100 km
	Max Speed	90
Engine	Type	C300 20/ C260 20
	Displacement/Power(kw)	8300/221 8300/191(300hp,260hp)
	Manufacturer	Dongfeng Commins Diesel Engine Co., Ltd
	Type	6-in-line
Chassis	Drive type	6×4
	Wheelbase(mm)	1900+5000+1300,1950+4250+1300
	Tread(front/rear)	1940/1860
	Front axle	5T double front bridge
	Rear axle	10T double rear bridge
	Steering gear	Duel-armed steering wheel,power steering
	Transmission	SAGGW 9 stalls gear box
	Clutch	Diaphragm spring clutch,Dia φ430MM
	Braking system	Spring braking, air braking, die braking
	Cab	Non-longheaded, high-top double sleeper
	Number of spring axle(front/rear)	8/10+7
	Tire Type	9.00-20,9.00R20
	Air-condition	Choose to fix
