concrete truss screed
Truss Screed powered by electric motor, provides uniform vibration over the entire blade length and enhances concrete compact - details see: https://www.machineto.com/concrete-truss-screed-10119353
Condition:New | Place of Origin:Zhejiang China (Mainland) | Brand Name:enjoy-engineering | Model Number:SF4 |
Power Source:Gasoline | Power(W):6.6kw(9hp) | Weight:92kg | Dimension(L*W*H):350x46x64cm |
Certification:CE | Warranty:1 year | After-sales Service Provided:Engineers available to service machinery overseas | blade length:optional |
Features :
1) Specially design, hardened aluminum blade ensuring a smoother finish than conventional screeds.
2) Heavy rubber mounts to reduce the vibration level on the handle.
3) Adjustable handle in height, vertical & horizontal position (optional)
4) The rounded ends of the blade make it easy to go around obstacles
5) The tilt-up stand keeps the engine out of concrete or off the ground obstacles.
6) One piece casting body easy connect to engine.
7)Emergency stop switch available.
8) different working widths: 6-18M
9)Easily changed blades.
Truss Screed |
Model | SF4-H |
Power section |
Length (m) | 3.1 |
Beam width(mm) | 355 |
Height(mm) | 475 |
Weight(kg) | 92 |
Engine type | Honda GX270 |
Max. output (kw) | 7 |
Max. speed(rpm) | 3600 |
Fuel Tank (L) | 2.9(4.0) |
Max. speed (rpm | 3600 |
Fuel Tank liter (gal) | 6 |
Center section |
Length(m) | 1.5 |
Beam width(mm) | 355 |
Height (mm) | 475 |
Weight (kg) | 26 |
End section |
Length(m) | 1.5 |
Beam width mm | 355 |
Height(mm) | 475 |
Weight(kg) | 30 |
optional lenght | 6-18M(1M,1.5M,3M section) |
Packing(cm) | Power Section: 350*46*64 Center Section: 176*46*62 End Section: 177*46*64 |
Packaging Detail:carton box |
Delivery Detail:15days |
