Coconut oil centrifuge separator

Coconut oil centrifuge separator can separate water and sludge from coconut oil. - details see: https://www.machineto.com/coconut-oil-centrifuge-separator-10302612

Condition:New	Type:Centrifuge	Product Type:Centrifuge machine	Place of Origin:Liaoning China (Mainland)
Brand Name:xianglong	Model Number:GF150	Voltage:380V, 50Hz or according to requirement	Power(W):4kW
Weight:665kg	Dimension(LWH):900X550X1600	Certification:ISO9001	Warranty:12 months after B/Ldate
After-sales Service Provided:Engineers available to service machinery overseas

contact supplier for Coconut oil centrifuge separator

The centrifuge is used for separating coconut oil from water and solids and separating various liquids that are

difficult for separation, especially adaptable for liquid-liquid separation / liquid-liquid-solid

separation. It is a high-speed centrifuge, with strong separating capacity. The bowl of the

centrifuge rotates around its axis and forms a strong centrifugal force, the centrifugal force

separates a mixture of two immiscible liquids that contain fine solids.

The mixture enters the centrifuge through an inlet at the bottom of the machine, and is introduced

into the hollow cylindrical rotor which has two outlets at the top to allow discharge of the separated

liquids. The bowl turns at 19000 r.p.m.or higher, and generates a centrifugal force in excess of

21000 times the force of gravity. This force separates the two immiscible liquids according to their

specific gravities into concentric cylindrical layers. The lighter liquid is nearer the centre of the

bowl and the heavy liquid forms the outside layer. The lighter liquid and the heavy liquid flow out

from their respective liquid outlets. At the same time the solids are deposited against the bowl

wall and the solids are cleaned out when the centrifuge is shut down.

The capacity of GF tubular centrifuge separator for coconut oil separating is from 200L/h to 3000L/h.

Items		Models
Items		GF75	GF105	GF125	GF150
Bowl	Diameter (mm)	75	105	125	150
	The Effective Height(mm)	450	730	730	730
	Volume (L)	2.2	6	8	10
	Speed of Rotation(r/min)	19200	16300	15000	14000
	Separation Factor(ω2.r/g )	15600	15250	15750	14300
Working pressure (MPa)		≥0.05
Output Capacity (L/h)		200~600	500~1200	1000~2000	1500~3000
Motor Power (kW)		1.5	2.2	3.0	4.0
Dimensions (L×W×H) (mm)		760x450x1120	840×500×1600	900×550×1600	900X550X1600
The weight		200	570	610	665
