Calcite Mill for Grinding Calcite to be Powder 30-325mesh

1) Application of calcite mill:

High Pressure Calcite Mill is a new kind of mill, which starts an epoch of high efficiency and low cost in international mining industry. High Pressure Pendulum Mill can be used to grind non-inflammable and non-explosive materials with Moh’s hardness below 9.3 and moisture content below 6%, such as calcite, bentonite, barite, limestone, pottery, scoria,etc.

Calcite Mill for Grinding Calcite to be Powder 30-325mesh

2) Advantages of calcite mill :

1. Compared with other mills, its capacity increases by 20%-30% under the same power condition, and compression force of rollers to material improve 800-1200 kgf under the force of high-pressure spring.
2. Size of final product can be 30–425 mesh. Some can reach the fineness of 1000 mesh.
3. Meets the requirement of national dust-dump standard.
4. The separator can be adjusted very easily.
5. The multi-class seals are adopted to keep the grinding equipment tightly closed.

Calcite Mill for Grinding Calcite to be Powder 30-325mesh

3) specifications of calcite mill:

Model	Piece of roller	Size of the roller (mm)	Feed size (mm)	Fineness of powder (mm)	Capacity (t/h)	Motor power (kW)	Fan Power (kw)	Dimension (MM) (L*W*H)
QMB6515	3	210*150	12-20	0. 613-0. 033	0.25-2	15	11	4100*3300*4500
QMB7815	3	260*150	15-20	0. 025-0. 005	0.28-3	18.5	15	4300*3500*5100
QMB8314	3	270*150	15-20	0. 025-0. 005	0.35-3.4	22	18.5	5300*4100*5200
QMB3016	3	300*150	15-20	0. 025-0. 005	0.35-4	22	18.5	5300*4100*5200
QMB9517	4	310*150	15-25	0. 025-0. 005	1.5-9	37	30	7100*5900*7900
QMB4121	5	410*210	15-25	0.613-0.044	4-8	75	55	7850*8000*9700
QMB4528	6	450*280	15-35	0.613-0.044	5-22	132	132	12550*5700*8300
