Best-selling Dual-chamber glass tempering furnace
| Condition:New | Machine Type:Glass Tempering Furnace | Place of Origin:Jiangsu China (Mainland) | Brand Name:mingsite |
| Model Number:MF-DF2450-4T | Certification:CE | Warranty:2 years | After-sales Service Provided:Overseas service center available |
| function:tempering |
Best-selling Dual-chamber glass tempering furnace
main technical parameters
1.Equipment External Dimension: 29720mm(L)×4100mm(W)×3100mm(H) (the fanning mill is set after the machine)
2. Installed Capacity:
Power Supply: Three-phase 380V; Four-wire 50 Hz
Gross Power:1760KW
a.Heating:700KW*2
b.Quick Cooling: 160KW×1set (variable-frequency control)
c.Others: 10KW
d.Air Compressor: 7kg/cm230KW, including the freeze drier and 0.5T air collector .
3. Compressed air pressure of actuating mechanism: <7kg/cm2
4.Comprssed air volume of actuating mechanism: <40L/min.
5.Air volume for thermal agitation: <4000L/min.
Maximum noise produced by the production line: <90 db
6.The ambient temperatureshould be controlled between 5 and 45°C.
7.The partition of the fanroom should be provided by the buyer.
The characteristics of the Dual-chamber glass temperingfurnace:
the output is 1.8 times of the reciprocation type with same dimenison, high-efficiency and energy-saving.
Application:household glass, phptovoltaic industry.
| Model | MAX mm | MIN mm | Gass thickness mm | Capacity m2/h | Heating KW | Quench KW |
| MF-DF1632-4T | 1600*3200 | 120*250 | 4.0-19.0 | 135 | 320*2 | 160 |
| MF-DF1642-4T | 1600*4200 | 120*250 | 4.0-19.0 | 180 | 450*2 | 220 |
| MF-DF1650-3T | 1600*5000 | 120*250 | 4.0-19.0 | 215 | 540*2 | 250 |
| MF-DF2436-5T | 2440*3200 | 120*250 | 5.0-19.0 | 240 | 560*2 | 132 |
| MF-D2442F-5T | 2440*4200 | 120*250 | 5.0-19.0 | 280 | 650*2 | 132 |
| MF-DF2450-5T | 2440*5000 | 120*250 | 5.0-19.0 | 330 | 700*2 | 160 |
| MF-DF2460-5T | 2440*6000 | 120*250 | 5.0-19.0 | 400 | 900*2 | 200 |
| MF-DF2480-5T | 2440*8000 | 120*250 | 5.0-19.0 | 540 | 1200*2 | 280 |
| MF-DF3050-5T | 3050*5000 | 120*250 | 5.0-19.0 | 410 | 860*2 | 200 |
| MF-DF306--5T | 3050*6000 | 120*250 | 5.0-19.0 | 490 | 1080*2 | 250 |
| MF-DF13080-5T | 3050*8000 | 120*250 | 5.0-19.0 | 650 | 1440*2 | 315 |
Photos for machine:
Apply to:
| Packaging Detail:packen in containers |
| Delivery Detail:90 working day |
