BENCH DRILLING MACHINE-ZT19GF

we are manufacture, our price is very competitive, we have strong producing ability, we have passed the IS9000 identicat - details see: https://www.machineto.com/bench-drilling-machine-zt19gf-10125487
Condition:NewCNC or Not:NormalDrilling Speed:250-3200Place of Origin:Shandong China (Mainland)
Brand Name:ZHONGXIANGModel Number:ZT19GFPower(W):550Dimension(L*W*H):800X560X340/1450X150X150
Weight:100/120Certification:IS9000After-sales Service Provided:Overseas third-party support available
BENCH DRILLING MACHINE-ZT19GF
contact supplier for BENCH DRILLING MACHINE-ZT19GF


(Model)
Specifications
ZT-19GF
Drilling capacity(mm)
19
Chuck size(mm)
16
Table travel(mm)
830
Table size(mm)
Φ 350
Spindle travel(mm)
100
Distance spindle axis to column(mm)
199
Spindle taper
MT2
Columm diameter(mm)
80
Spindle speeds range(r.p.m)
250-3200
Spindle speeds series
12
Motor power(HP)
3/4
Overall height(mm)
1625
N.G./G.W.(kg)
100/120
Packing case dimensions(mm)
800×560×340
1450×150×150

BENCH DRILLING MACHINE-ZT19GF
Packaging Detail:carton,wooden box
Delivery Detail:within a week after receiving the order
