ball mill, 1.ISO9001:2008, 2.good quality&competitive price, 3.capacity:2-5t/h, 4.long service life - details see: https://www.machineto.com/ball-mill-10313927

Ball mill

Ball Mill is important for the secondery grinding. After the material entering the hollow axis by the feeder, the material will be taken evenly and spirally into the first warehouse, where there is the ladder liner or the ripple liner with the differentball-mill steel balls will be carried higher to some extent, and then fall down to strike and grind the material. After grinded generaly in the first warehouse, in which there is the flat liner, the material will be regrind and then be discharged through the discharge grate liner.
It is widely used for the cement, the silicate produce, new type building material, chemical fertilizer, black and non-ferrous matal glass, ceramics and etc. Two kinds of process methouds, wet process of by dry process are both avalibale.

Technical parameters

Model	Rotary Speed (r/min)	Capacity (t/h)	The Feeding Size(mm)	The Final Size(mm)	Main Motor(kw)	Weight(t)
MQG900×1800	38	0.65-2	≤20	0.075~0.89	18.9	3.6
MQG900×3000	38	1.1-4.8	≤20	0.075~0.89	22	4.6
MQG1200×2400	32	1.5-4.8	≤25	0.075~0.6	45	12.5
MQG1200×2800	35	1.2-3.7	≤25	0.074~0.4	30	11.5
MQG1200×3000	32	1.6-5	≤25	0.074~0.4	45	12.8
MQG1200×4500	32	1.6-5.8	≤25	0.074~0.4	55	13.8
MQG1500×3000	27	2-5	≤25	0.074~0.4	75	17
MQG1500×4500	27	3-6	≤25	0.074~0.4	90	21
MQG1500×5700	27	3.5-6	≤25	0.074~0.4	110	24.7
MQG1830×3000	24	4-10	≤25	0.074~0.4	180	28
MQG1830×6400	24	6.5-15	≤25	0.074~0.4	210	34
MQG1830×7000	24	7.5-17	≤25	0.074~0.4	245	36
MQG2200×5500	21	10-22	≤25	0.074~0.4	370	48.5
MQG2200×6500	21	14-26	≤25	0.074~0.4	380	52.8
MQG2200×7000	21	8-36	≤25	0.074~0.4	380	50
MQG2200×7500	21	16-29	≤25	0.074~0.4	475	56
MQG2100×2700	24	3.5-25	≤25	0.074~0.4	150	33
MQG2100×3500	24	4.5-33	≤25	0.074~0.4	180	37
