AUTOLEVELLER DRAW FRAME

Two deliveries drawing frame with autoleveller - details see: https://www.machineto.com/autoleveller-draw-frame-10279311
Place of Origin:Hubei China (Mainland)Brand Name:TianheModel Number:TMFD81LVoltage:380V, 3 Phase
Warranty:one yearAfter-sales Service Provided:Engineers available to service machinery overseas
AUTOLEVELLER DRAW FRAME
contact supplier for AUTOLEVELLER DRAW FRAME


Drawing Frame TMFD81L

Salient Features:

  1. Uster UQA short-term auto-leveler, driving and control system are separate for each head, to achieve optimum results.
  2. Use programmable logic controller (PLC), touch screen display, frequency control of motor speed, etc.
  3. Differential box is specially manufactured, two steps integration, to get high dynamic response and leveling efficiency.
  4. Compact structure, rational lay-out, good interference-resist capability.
  5. 3 over 3 double zone curvilinear draft system with guiding top-roller and pressure bar.
  6. Adjustable draft ratios for coiler, front draft, back draft and creel, bring more flexibility to the machine for various fibers.
  7. Available for automatic filter cleaning and sliver breaking for full can.
  8. Spring loading is for sliver feeding measure, good dynamic response and high accuracy.
  9. Preset intranet interface is convenient for central management.

Technical specifications:

Range of Application

Fiber length up to 76mm combed and carded cotton, chemical fiber and blends

Number of Delivery

Two

The highest output speed

800m/min
Doubling6~8

Roller Dia.

Top Roller34 34 34mm
Bottom Roller40 35 35mm

Drafting System

3 over 3 double zone curvilinear drafting system with pressure bar and guiding top-roller.

Total Draft (between 1stand 3rdrollers)

5.67~9.8

Can Size

Input400 500 600mm Height 1100mm
Output350 400 500mm Height 1100mm

Feeding Form

Overhead creel lengthwise positive feeding

Main Motor

4.7Kw

Power of suction blower

1.5Kw

Power of servo motor

2*1.1Kw
AUTOLEVELLER DRAW FRAME
Packaging Detail:Export seaworthy wooden case
Delivery Detail:2 months
