ARC 200A stick welder

High welding quality ,deep bath and strong strength, Auto protection of over-voltage and over-current - details see: https://www.machineto.com/arc-200a-stick-welder-10135699

Place of Origin:China (Mainland)	Brand Name:USR	Model Number:Digital ARC200	Input Voltage:220V
Output Power:7.3KW	Dimensions:440180330mm	color:yellow

contact supplier for ARC 200A stick welder

Main Characteristic:
Minimizing, lightness, high quality and energy saving Advance arc force and arc-starting function can rest Interference Stable arc and little splash High welding quality ,deep bath and strong strength Auto protection of over-voltage and over-current Be able to work continuously, it can balance automatic, When voltage is waving Suit for welding all kind of basic welding rod Be able to weld cellulose rod

TECHNICAL SPECIFICATIONS

MODEL	DigitalARC160	DigitalARC200	DigitalARC220	Digital ARC250
AC Input Voltage	AC.single phase 110V~240V			three phase 220V~415V
Rated input power capacity	5.3	7	7	9.4
Input frequency	50/60	50/60	50/60	50/60
No-load voltage	56	63	63	54
Output current range	30-160	20-200	20-220	20-250
Rated output coltage	27	28	28	30
Duty cycle	60	60	60	60
No-load power	40	40	40	60
Efficiency	85	85	85	85
Power factor	0.93	0.93	0.93	0.93
Insulation class	B	B	B	B
Weight	7.5	8	12	13
Overall dimension	440180330	440180330	440180330	490180330
Protection class of case	IP21	IP21	IP21	IP21
Drive adjustment range				0-100
Welding thickness	1.6-2.8	1.6-3.2	1.6-3.2	1.6-4
