agricultural products dryer machine, 1.hot air circulating drying oven, 2.capacity:50-400kg/h, 3.various kinds of food ,veget - details see: https://www.machineto.com/agricultural-products-dryer-machine-price-10293868

agricultural products drying machine

The steam or electricity is used as the heat source. The axial fan is used for heating the air of the heat exchanger

in node of convective heat exchanging. The hot air stream transfers the heat to the material through the drying

tray.The fresh air enters the drying box through air inlet hole for making up. The humid air is exhausted from

the dehumidifying hole. In this way, the machine keeps the proper relative humidity in the drying box.

2.Main applications of this oven

Hot air circulation oven is suitable for heating and dehumidifying of raw materials and products for pharmacy

eutical,chemical,foodstuff and light and heavy industries,Such asmedicinematerial,medicine powder ,kinds of

food ,fish ,fruit ,fruit slice ,vegetables ,herbs and so on

3.Main features of this oven

1>.An universal drying eqyipment

2>.material : shelves,trays,heating tubes,oven inside and outside walls are all 304 stainless steel

3>.Most of the hot winds are cycled within the box. It has high transmission efficiency, and can save energy.

4>.By making of the forced ventilation,the upper and lower temperature difference can be reduced,the material

can be Uniform dried

5>.It is characterize-ed by Iow noise, stable operation,automatic temperature-control and convenient maintenance. This is according with the requirements of GMP.

6>.Automatic controlling system for the heating temperature and the heating time

7>.two kinds of heat source :steam and electric

8>.our oven can be custom-made,we will give customer the bestsolutionaccording to their requirement

4.Working principle of oven

The steam or electricity is used as the heat source. The axial fan is used for heating the air of the heat exchanger in node of convective

heat exchanging. The hot air stream transfers the heat to the material through the drying tray. The fresh air enters the drying box through

air inlet hole for makingup. The humid air is exhausted from the dehumidifying hole. In this way, the machine keeps the proper relative

humidity in the drying box.

5.We have five kinds of hot air circulating oven ,here's parameter for reference

ModelNo.	Capacity(kg/h)	Poweroffan(kw)	Volumeofwind(m³/h)	Amountofoven	Amountofbaker	Meas.(mm)	Weight(kg)
GL-RCXTH0	50	0.45	3450	24	1	1430×1350×2100	350
GL-RCXTH1	100	0.45	3450	48	2	2430×1350×2300	500
GL-RCXTH2	200	0.90	6900	96	4	2430×2350×2300	900
GL-RCXTH3	300	1.35	10350	144	6	3220×2430×2300	1300
GL-RCXTH4	400	1.80	13800	192	8	4460×2200×2290	1800
