718L Low Humidity Electronic Dry Cabinet DC87183L
1. Outside:W598*D710*H1910mm, 2. Inside:W596*D682*H1723mm, 3. Capacity:718L, 4. Weight: 65kg - details see: https://www.machineto.com/718l-low-humidity-electronic-dry-cabinet-dc87183l-10288307
Condition:New | Type:Dry Cabinet | Place of Origin:Jiangsu China (Mainland) | Brand Name:SSL |
Model Number:DC87183L | Voltage:85V-265V, 50HZ/60HZ | Power(W):20 | Dimension(L*W*H):1910*598*710mm |
Weight:65 kg | Certification:ISO9001 | Warranty:1 year | Display:Honeywell |
Ultra Low Humidity Type-Single Door Type
Cabinets suitable for processing and storage of electronic components.
Production Description |
| - Humidity adjustable, energy saving design digital LED-Honeywell display and control.
- 1.0mm thickness steel body, rustproof paint, 3.2mm toughened glass.
- Moisture absorbs continuously with sustention for 24hours
- Equipment with high performance, reliable desiccators and humidity controller located at the lower deep inside.
- Zinc alloy lock with plus pressure capability. Anti-ESD powder coating, dark green look. Surface powder coating with RoHS certification.
- Slip layer board make the inter space adjustable.
- Noisy free, vibration free, low humidity keeping at ambient temperature and long-term consecutive driving.
| Name | Value | Brand | SSL | Model | DC87183L | Voltage | 85V-265V, 50HZ/60HZ | LED Display | Yes (Honeywell) | Capacity | 718L | Weight | 65 kg | Ext. sizes(H*W*D) | 1910×598×710mm | Int. sizes(H*W*D) | 1723×596×372mm | Sheet | 5 pcs, each with 100kg loading | Warranty | One year |
|
|
Application |
Its typical applications include the prevention and protection against all types of oxidation (rust), the prevention of the growth of fungus on optics, the dry preservation of lab materials and samples as well as the protection of MSDs (moisture sensitive devices) as per IPC/JEDEC J-STD-033 within the electronics industry. It is suitable for storing: photographic & optic lens, cameras or digital photography, audiovisual, precise instruments, food, paper materials, films, ect.
|
|
RH% | ITEMS |
1%-20% RH | Electronic components, chemicals, MSD, LED |
20%-30% RH | IC, CHIP, SMT, wafer, precise instrument, poise, PCB, BGA |
30%-40% RH | Semiconductor, capacitance, resistors, circuit board, filament, nickel-cadmium batteries, electronic machine, precision measuring instruments, medicine, mould, battery-chip, tea, seed, stamps. |
40%-50% RH | cameras, lens, microscope, endoscopy, video cameras, roll film, disc, photographic film, floppy disk, rigid disk, DVDs, leather, jewelry |
Details show
Packaging Detail:paper box for FCL, crate for LCL |
Delivery Detail:7-10 days for lcl, 25-30 days for fcl |
