2013 Limestone Micro Powder Grinding Raymond Mill

Limestone Micro Powder Grinding Raymond Mill:, 1.Dry and wet grinding types, 2.Longer linning service life, 3.Low cost - details see: https://www.machineto.com/2013-limestone-micro-powder-grinding-raymond-mill-10314632

Condition:New	Type:Raymond Mill	Motor Type:AC Motor	Power(W):Y225m-8-30
Capacity(t/h):0.5-3	Place of Origin:Henan China (Mainland)	Brand Name:Hongxing	Model Number:93-micro Powder Mil
Weight:5.5-35t	Certification:ISO9001	Warranty:1 Year	After-sales Service Provided:Engineers available to service machinery overseas
Application:ore ,stone like gysum and liome stone	Max feeding size:25mm	Size of Products:0.125-0.01mm	Rotate speed of central shart:160 r/min
Diameter of roller:300 mm	Main Motor:Y225m-8-30	Fan motor:Y160E-2-22	Analyzer motor:Y112m-4A-3
Installation:drawing offered or engineer sent	Spare parts:Yes ,we supply at best price

2013 Limestone Micro Powder Grinding Raymond Mill

contact supplier for 2013 Limestone Micro Powder Grinding Raymond Mill

Micro powder grinder Raymond Mill Description:

Raymond mill is used for grinding the barite, limestone, kaolin, cerames, ahd slags, etc, below scale 9.3 of Mohs hardness and 280-odd sorts of non-inflammable and non-explosive stuff in the trades of mining, metallurgical industrial, chemical engineering and building material for high fine powder generation and processing.

Micro powder grinder Raymond Mill Product Size:

The product size is adjustable in the range of 80-325 (600 the largest) meshes. It is possible to produce 30-80 mesh coarse powder through special device in the machine.

Working principles:

When it is put into use, the materials to be grinded are put into the main frame through the feed-in bin on the side cover. Then it revolves round the vertical axis line by the milling roller hung on the star rack. With the centrifugal force by rotation, milling roller wings outside and presses fast on milling rings to make relieving tool carry materials between milling roller and ring, thus the materials are crushed by the rolling and milling of the milling roller.

Technical parameters

Model	6R4525	5R4119	4R3216	3R90	3R85	3R75	3R65	3R60
Model	6R4525	5R4119	4R3216	4R90	4R85	3R75	3R65	3R60
Particle size of feed (mm)	<=30	<=25	<=25	<=25	<=20	<=20	<=15	<=15
Particle of finished product(mm)	0.125- 0.044	0.125- 0.044	0.125- 0.044	0.125- 0.044	0.125- 0.044	0.125- 0.044	0.125- 0.044	0.125- 0.044
shift output at different material fine degree(t)	16-120	8-60	4-45	3-35	2-28	1.5-20	1-18	0.5-8
Rotate speed of central shaft (r/min)	82	105	130	160	160	160	180	280
Inner diameter of pulverzing ring (mm)	1770	1400	1073	973	885	865	725	495
Diameter of pulverzing roller(mm)	450	410	320	300	270	260	210	140
Height of pulverizing ring(mm)	250	190	160	160	150	150	150	100
Electrical machine of main frame	y315m- 4-132	y280s- 4-75	y225s- 4-37	y225m- 8-30	y225m- 8-22	y225s- 8-18.5	y200L- 8-15	y160m- 6-7.5
Electrical machine of blower	y315m- 4-132	y250m- 4-75	y200L- 4-37	y180m- 4-22	y160L- 4-15	y160L- 4-15	y160m- 4-11	y132s- 2-5.5
Electrical machine of analyzer	y160m- 4-11	yc200- 4B-7.5	yc120- 4a-5.5	y112m- 6-2.2	y112m- 6-2.2	y112m- 6-202	y112m- 6-2.2	y90L- 6-1.1

Sharp tools make good work

Hongxing has bought advanced manfacturing equipments from home & abroad.Numerical control machine tools with high-precision,large processing equipments & special test equipments provide strong safeguard for product quality and company development

Green industry and internationalization is the strategic thought of Hongxing.Hongxing tries best to integrate the advanced technology,excellent talents and advanced concept into the company development,which give support to the pace,strategy and development of Hongxing's internalization and make our business partners using most suitable Hongxing's product .

Excellent quality identified by all the Qualifications

We know what Hongxing gets from the society is more than her contributions to the society Hongxing cannot develop itself in isolation of the society Over the years,Hongxing's staffs have been grateful to the society,what thery can do is to regard product quality as company's life and innovation as object , dedicated to return society,put its strength for the indestrial and national

development.
