LBXH 2500P 2013 Hot Sale Glass production Machinery

Main Features:

This Double Glazing Insulated Glass machine is composed of glass loading section, washing and drying section, and light inspection section, spacer bar attaching section, out-panel assembly section, panel press section and lifting table.

1.Imported low tension electrical elements,sensor and PLC control.

2.Automatic control for LOW-E glass,automatically distinguish the coating side of coated glass and LOW-E glass.

3.Safe hydraulic system for safe processing.High efficiency ,storage for the small pieces of glasses. Wash glass continuously.

4.Proface touch screen ,user friendly design. Dynamic display of the working process and break down during the working .

5.It can produce the overlength ,large and small pieces of glass,also can produce the normal and different shape insulating glass and the three-ply insulating glass.

6.Washing and drying section is made of stainless steel ,three pairs of brushes are controlled independently,automatic washing of the LOW-E glass and and won't break the coating.

Technical specifications:

Machine Type Insulating Glass Production Line

Place of Origin Shandong, China (Mainland)

Brand Name Hengdi Model Number LBXH2500

Certification CE

Warranty whole life After-sales Service Provided Engineers available to service machinery overseas

Total power 28Kw

Cleanout speed 2--8m/min

Max.work speed 45m/min

Min.glass size 450*450mm

Max.glass size 2450*3150mm

Max Insulating glass thickness 48mm

Compressed air flow:0.8m³/min

Electrical conductivity of water ≤50us/cm

Dimension 25900*1800*3350mm
