we are one of the most professional manufacturers, who specialize in ball-tube mill for export - details see: https://www.machineto.com/2013-china-made-ball-tube-mill-manufacturer-10314211

These kind of rpoducts are widely used for fine-grinding of medium hardness material in industrial field, such as mineral seperation plant, fire-resistance material plant, cement plant and glass plant, etc. Wet type is to have material water-permeated before grinding. Dry type is not allowed to have material water-permeated.

Main technical parameters

model	diameter (mm)	length (mm)	rotational speed (r/min)	effective volume (m)	weight (T)	working capacity (t/h)	put the ball to heavy (T)	model	power (kw)	feed lump size (mm)	material-out size (mm)
Φ900x900	900	900	38	0.5	4	0.22-1.07	0.9	Y180L-6	11	≤25	0.07-0.6
Φ900x1800	900	1800	38	0.9	5.5	0.33-1.6	1.8	Y200L-6	12	≤25	0.07-0.6
Φ900x3000	900	3000	38	1.5	6.5	0.58-2.5	2.5	Y225M-6	22	≤25	0.07-0.6
Φ1200x2400	1200	2400	32	2.2	13	0.4-5.8	4	Y280S-6	30	≤25	0.07-0.6
Φ1200x4500	1200	4500	32	4.1	15	1.2-7.5	5.2	Y280M-6	55	≤ 25	0.07-0.6
Φ1500x3000	1500	3000	28	4.2	15.5	2.8-10	8	JR116-8	70	≤ 25	0.07-0.6
Φ1500x4500	1500	4500	28	6.5	17	2.8-11	10.5	JR126-8	110	≤ 25	0.07-0.6
Φ1500x5700	1500	5700	28	8.5	23.2	4-12	12	JR127-8	130	≤ 25	0.07-0.6
Φ1830x6400	1830	6400	23.9	13.5	33	6-18	19	JR137-8	210	≤ 25	0.07-0.6
Φ1830x7000	1830	7000	23.9	21	34.5	6-19	21	JR138-8	245	≤ 25	0.07-0.6
Φ2100x3000	2100	3000	22.8	9	30.1	5-40	18	JR138-8JR137-8	210	≤ 25	0.07-0.6
Φ2100x7000	2100	7000	22.8	24	41.5	5-45	25	JR148-8	380	≤ 25	0.07-0.6
Φ2200x7500	2200	7500	22	26	45.5	7-50	31	JR148-8	380	≤ 25	0.07-0.6
Φ2400x7500	2200	7500	20.4	28.5	60	10-60	36	JR157-8	440	≤ 25	0.07-0.6
Φ2600x13000	2600	13000	20	63.8	105	16-70	60	MFY100-8	1000	≤ 25	0.07-0.6
