2013 Best Energy-saving Grinding Ball Mill -Yufeng Brand

Energy-saving Grinding Ball Mill:, 1 High efficiency, 2 Fine product, 3 nice price with grinding balls, 4 spare parts suppy - details see: https://www.machineto.com/2013-best-energy-saving-grinding-ball-mill-yufeng-brand-10314543

Condition:New	Type:Ball Mill,grinding mill, ball mill, grinder	Motor Type:AC Motor	Capacity(t/h):0.65-90
Place of Origin:Henan China (Mainland)	Brand Name:Yufeng	Model Number:9001800--32004500mm	Certification:ISO9001:2008,CE
Warranty:24months	After-sales Service Provided:Engineers available to service machinery overseas	Application:grinding cement, silicate,building material,glass ceramics	Grinding way:Wet or dry
Rotational speed:18-42r/min	Particle size:1-1000mesh	Discharging granularity(mm):0.075-0.89	Motor power(KW):0.65-90
Feeding granularity(mm):≤25	guarantee:one year

Energy-saving Grinding Ball Mill introduction:

Energy-saving Grinding Ball Mill is a key equipment to grind the crushed materials, and the ball mill is widely used in powder-making production line including cement, silicate, new-type building material, refractory material, fertilizer, ore dressing of ferrous metal and non-ferrous metal, glass ceramics, etc, and the ball mill can grind various ores and other materials with dry type and wet type.

There are two kinds of ball mill, grate type and overfall type due to different ways of discharging material. Energy-saving Cone Ball Mill. This Cone Ball Mill changes the intrinsic grinding machine structure. ball mill body and ground plank are an integral whole, so when fixing, ball mill can be lowered on a plane surface once only. Using double tiered roller axletree with centripetal spherical surface as the support of the host axletree can reduce energy cost by 30%.The intrinsic grille pattern forcing evacuation of ball mill is instead by overfall pattern controlling one. ball mill can improve the milling of the granule and the capacity of the ball mill be increased by 15-20%.

Working principle of Energy-saving Grinding Ball Mill:

When the Ball Mill works,motor and speed reducer transmit torque force to big and small gears of Ball Mill,so the barrel rotates.When the barrel rotates,Steel balls or other grinding media in the barrel are lifted to a certain height and fall down freely,so materials in the barrel are impacted.Grinding media mixing with materials impact and grind materials continuously.The grinding media and materials impact and grind each other when the Ball Mill rotates continuously.The final product will be discharged from outlet when it meets the request,so the grinding process is finished.

Advantages of Energy-saving Grinding Ball Mill:

1.Ball mill's Double-row self-aligning spherical roller bearing replaces babbit-lined bearing. Friction resistance is greatly lowered down, easy to start and 20-30% of energy is saved.

2.Ball mill's Grooved and ringed liner increases contacting surface between balls and ores, improving milling effect and saving energy through its lifting effect to the materials.

3. Ball mill's All-in-one frame is used in middle-sized or small-sized machinery, facilitating engineering construction and equipment installation.

4.Ball mill's Large discharging outlet and high capacity,discharge coarse particles,usually used in first stage milling.

5.The Energy-saving Cone Ball Mill can be used for grinding particles in the process of metal mineral resouces, such as gold, silver, iron, copper, lead, zinc etc., and non-metal mineral resources.

Main technical parameters of Grinding Ball mill:

Training & service

Training is FREE to every customer. Whenever you need us, for installation, maintenance, or proper use of our company machines, we will be right there for you. In addition, we provide 2-years warranty to make sure your machine runs consistently. We always keep certain inventory level of spare parts, which means the replacements can be shipped to you right away.

Why choose Yufeng Company

We are manufacturer in Zhengzhou, which serves as the largest base of Chinese industrial technology, and the busiest container port in the world. The competition in this city is severe, only companies with ending technology, stable workforce, and effective cost management could survive. With 25 years of efforts and innovation,our company is now a leading brand in China.

Affordable, high-quality machines. Our highly competitive price relies upon our ability to minimize our costs, of which ourcompetitors don’t.

1. We are factory(NOT Dealer)

2. We own our factory & Land (NOT Rent)

3. Staff reside in factory(Stable Workforce)

Producing high-quality and reliable machines is always our first priority, because we know that our success depends entirely on the satisfaction of our customers. We never give-up quality to save cost, instead we manufacture our machines to supply you the best need.

If you have any other questions about our products, you may contact Marcie through skype: yufmachinery or mobile cell: 0086 15890080350.
