15KW automatic PVC coating fabric high frequency welding machine

Automatic High frequency welding machine, 15KW fabric coated welding machine, NL-5557, Laser location, Span length 75cm, OEM,CE - details see: https://www.machineto.com/15kw-automatic-pvc-coating-fabric-high-frequency-welding-machine-10139369
Place of Origin:Guangdong China (Mainland)Brand Name:HipowerModel Number:HR-15KW-F1Voltage:3p 380V/220V 50/60HZ
Power:15kwFrequency:13.56MHzWelding Area:500/650 cm2Dimensions:1700*1480*1740
Weight:500kgUsage:PVC coated fabric weldingAfter-sales Service Provided:Engineers available to service machinery overseascolor:green or customize
15KW automatic PVC coating fabric high frequency welding machine
contact supplier for 15KW automatic PVC coating fabric high frequency welding machine


15KW automatic PVC coating fabric high frequency welding machine

Application:PVC projection fabric high frequency welding, PVC coated fabric welding, PVC ceiling welding, PVC awning welding, PVC canvas welding etc.

Features of 15KW automatic PVC coating fabric high frequency welding machine:

1.Machine groove deep and wide ,convenient in continuous welding with large area.
2.the length span is 600mm, internal occupation can reach 1000mm
3.With the function of automatic welding and connection, the welding area can reach 30*700mm one time
4. also can weld two lines as optional.
5. Firmly weld ,be well meeting with materials of thick or thin.
6. It is convenience in continuous welding, the welding length is optional
7. The distance of body from horn can be customized.
8. Adopting high sensitive anti sparkle device NL5557 to avoid damaging the mould.
9. High quality imported apparatus, Facilitate large-scale continuous connection.
The longest welding extended to 800mm for one welding process.
10.European standard high-frequency oscillatory square box, more reliable and Stable in output.
11.All sizes available related machines made by request
12. Laser scan system, precise positioning welding.

Specifications of 15KW automatic PVC coating fabric high frequency welding machine:

ModelHR-15KW-F1
Power15000W
Voltage3P 380v 50Hz or customize
Frequency13.56MHz
Input power25KVA
Oscillation tube8T85RB
Max pressure1000KG
Operation modePneumatic
Max gap of electrodes100mm
Size of active horn100mm
The size of upper electrode60*60*1000mm
The size of lower electrode400*1050mm
Welding time0.01~9.99s adjustable
Net weight600kg
Overall dimension1700*1480*1740

Samples:

Before-sales service

Our free technical assistance is available to you from now on:

1. Recommend equipment of top choice based on your requirements for product;

2. Examining mold drawings on your behalf to confirm optimum structure size meeting ultrasonic process and high frequency process;

3. Providing assistance in manufacturing and modifying tools;

4. Sample for welding.

During-sales Service

1. Punctual deliver of equipment as per Contract;

2. Free door to door service for installation and debugging;

3. Professional training for operators;

4. Our engineering instruction will guarantee your productive manufacturing of top-quality products.

After-sales service

1. Available within 24hours within Guangdong Province and 48hours beyond the province;

2. Our regular return visits ensure continuous improvement of our service quality

15KW automatic PVC coating fabric high frequency welding machine
Packaging Detail:standard wooden case
Delivery Detail:15 to 25 working days
