Rod Mill, 1.Rod mill widely use in grinding, 2.Improve finess of discharging, 3.ISO9001:2000 - details see: https://www.machineto.com/rod-mill-for-sale-10314637

rod Mill

rod Mill Introduction
At present, the sand maker-rod mill is the most effective crushing machine. its performance has achieved the international standard. And it is one of the gravel equipments for building widely used in the gravel industry. It is mainly used for processing or crushing the feldspar, quartz, minerals and other raw materials, and it is also suitable for finely or secondarily crushing the various tough or brittle materials, such as grinding material, refractory material, cement, steel shot, pulverized slag, Copper Ore, iron ore, gold ore, concrete aggregate, bituminized aggregate. Now it is a most advanced sand-maker in the world.
Depending on the reduction box and the reduction of the peripheral big gear wheel, the motor rotary drives the cylinder rotating or the motor drives the cylinder rotating directly by the peripheral big gear wheel. And inside the cylinder, there’s an appropriately grinding medium-steel bar .The steel bar will drop after reaching a certain height with friction and the centrifugal force. And the material will be hit and grinded to achieve the purpose of making sand.
Features and Benefits
1. Higher capability and more even discharging size. Adopted advanced technology of sand maker-rod mill by controlling the input or output materials; related to the user’s actual grinding materials, choosing an appropriate grinding medium, replaced the traditional surface contact to the linear contact . Therefore, its discharging size is more even, the capability is higher, suitable for various hardness of ore.
2. Adjustable fineness of limestone. Through simple adjustment, will change the discharging size ,and inside , has finesse control device and screening device, ensuring not over grinding and avoiding the unqualified product interfusing into end products.

Model	Barrel size(mm)	Effective volume(m3)	loading capacity(t)	Rotating speed(r/min)	Pow(kw)	Discharge size(m)	Capacity(t/h)	Weight(t)
MB0918	φ900×1800		2.3	29	22	2.5-0.2	6-1.6	6.2
MB0924	φ900×2400		3.1	29	30	2.5-0.2	10-2.9	6.6
MB1224	φ1200×2400		6.5	27	55	2.5-0.2	5~13	13.5
MB1530	φ1500×3000	5	8	23	75	2.5-0.2	12-5.5	16.71
MB1830	φ1800×3000	6.5	17	22.8	132	2.5-0.2	20-9.5	29.8
MB2122	φ2100×2200	6.7	18	20.9	160	2.5-0.2	12~17	42.5
MB2130	φ2100×3000	9.2	25	20.9	160	2.5-0.2	30-13	43.9
MB2136	φ2100×3600	11	28	20.9	200	2.5-0.2	35-14.8	49.4
MBZ2136	φ2100×3600	11	32.5	20.9	210	-5	61.5-43	49.9
MB2140	φ2100×4000	12.2	31	20.9	220	2.5-0.2	38-17	50.3
MB2145	φ2100×4500	13.8	35	20.9	250	2.5-0.2	43-19	51.8
MB2430	φ2400×3000	12.2	31	19	250	2.5-0.2	47-22	56
MBZ2430	φ2400×3000	12.2	31	19	250	-5	73-52	58.3
MB2436	φ2400×3600	14.6	37	19	280	2.5-0.2	55-26	61
MBZ2436	φ2400×3600	14.6	37	19	280	-5	84-60	62.4
MB2736	φ2700×3600	18.4	42	17.5	355	5-0.8	150-45	81.8
MB2740	φ2700×4000	20.5	47	17.5	400	5-0.8	165-50	84.3
MB3040	φ3000×4000	25.9	50	16.2	500	5-0.8	206-62	130
MB3245	φ3200×4500	33	56	15.5	630	5-0.8	228-70	138
MB3645	φ3600×4500	40.8	78	14.5	800	5-0.8	270-83	168
MB3654	φ3600×5400	50	94	14.5	1000	5-0.8	340-103	192
