high output continuous forged steel ball mills

high output continuous forged steel ball mills:, 1. simple structure, 2. convenient maintenance - details see: https://www.machineto.com/high-output-continuous-forged-steel-ball-mills-10314741

Condition:New	Type:Ball Mill	Motor Type:AC Motor	Power(W):400000
Capacity(t/h):12-75	Place of Origin:Henan China (Mainland)	Brand Name:ESONG	Model Number:3200*3600
Dimension(LWH):330033003800mm	Weight:86T	Certification:CCC ISO	Warranty:12 month
After-sales Service Provided:Engineers available to service machinery overseas	Note:2 years wearing parts for free	Name:high output continuous forged steel ball mills	Rotational speed:20.2r/min
Ball load:52t	Feeding size:less than 25mm	Discharge size:0.074-0.4mm	Capacity:12-75t/h
Motor power:400kw	Dimension:330033003800mm

Features of the ball mill

1. Ball Mill is mainly used to grind materials in mineral, cement, refractory, chemical industry, etc.

2. Ball Mill has dry and wet ways.

3.When wet Ball Mill works, certain water and other liquid will be added into materials to increase flowability of materials, so the capacity is increased.

4.When dry Ball Mill works, capacity is affectedbecausematerial flowability is reduced, so absorbing wind device is needed on the outlet of Ball Mill, and then negative pressure is formed in the ball mill to increase flowability of material, so the capacity is increased.

Mining ball mill

Ball mills are used extensively in the mechanical alloying process in which they are not only used for grinding but for cold welding as well, with the purpose of producing alloys from powders.

Details of mining ball mill

The ball mill is a key piece of equipment for grinding crushed materials, and it is widely used in production lines for powders such as cement, silicates, refractory material, fertilizer, glass ceramics, etc. as well as for ore dressing of both ferrous non-ferrous metals. The ball mill can grind various ores and other materials either wet or dry. There are two kinds of ball mill, grate type and overfall type due to different ways of discharging material. There are many types of grinding media suitable for use in a ball mill, each material having its own specific properties and advantages. Key properties of grinding media are size, density, hardness, and composition.

Steel ball of mining ball mill

Main technical parameters

Model	Rotational speed (r/min)	Ball load (t)	Feeding size (mm)	Discharge size (mm)	Capacity (t/h)	Motor power (kw)	Weight (t)
900×1800	36-38	1.5	≤20	0.075-0.89	0.65-2	18.5	4.6
900×3000	36	2.7	≤20	0.075-0.89	1.1-3.5	22	5.6
200×2400	36	3	≤25	075-0.6	1.5-4.8	30	12
1200×3000	36	3.5	≤25	0.074-0.4	1.6-5	37	12.8
1200×4500	32.4	5	≤25	0.074-0.4	1.6-5.8	55	13.8
1500×3500	29.7	7.5	≤25	0.074-0.4	3.3-8.8	75	16.5
1500×4500	27	11	≤25	0.074-0.4	3-6	90	21
1500×5700	28	12	≤25	0.074-0.4	3.5-6	130	24.7
1830×3600	25.4	13	≤25	0.075-0.8	4-8	130	30
1830×4500	25.4	15	≤25	0.074-0.4	4.5-12	155	32
1830×6400	24.1	21	≤25	0.074-0.4	6.5-15	210	34
1830×7000	24.1	23	≤25	0.074-0.4	7.5-17	245	36
2100×3000	23.7	18	≤25	0.075-0.8	4.5-33	180	37
2100×4500	23.7	24	≤25	0.074-0.4	8-43	245	42
2100×7000	23.7	26	≤25	0.074-0.4	8-48	280	50
2200×4500	21.5	27	≤25	0.074-0.4	9-45	280	48.5
2200×7000	21.7	35	≤25	0.074-0.4	15-28	380	54
2200×7500	21.7	35	≤25	0.074-0.4	15-30	380	56
2400×4500	21	30	≤25	0.074-0.4	8.5-60	320	65
2700×4000	20.7	40	≤25	0.074-0.4	12-80	400	94
2700×4500	20.7	48	≤25	0.074-0.4	12-90	430	102
3200×3600	20.2	52	≤25	0.074-0.4	12-75	400	86
3200×3600	18	65	≤25	0.074-0.4	125-130	800	137
