high efficient screw sand washer with ISO9001:2000

Specifications Screw Sand Washer, 1.Simple structure, 2.Mile-fineness sand seldom lapses out, 3.WITH ISO9001:2008 - details see: https://www.machineto.com/high-efficient-screw-sand-washer-with-iso9001-2000-10319208

Place of Origin:Henan China (Mainland)	Brand Name:Yufeng brand	Model Number:screw washer	Condition:New
After-sales Service Provided:Engineers available to service machinery overseas	Type::screw washer	Brand name::Zhengzhou Yufeng	Model number::as your specific demand
capacity(t/h)::220-450t/h	application::limestone,caco3,talc,barite,granite, etc...	Main motor(kw)::110	warranty::2 years
Spare parts::supply for the whole two years	Installation::engineer guide on site	After-sale service::for whole using life

high efficient screw sand washer with ISO9001:2000

contact supplier for high efficient screw sand washer with ISO9001:2000

ZhengZhou Yufeng Heavy Machinery Co,.Ltd (www.yufmachinery.com) is a professional manufacturer of Screw Sand Washing Machine.

The XSL series of grit stone washing and selecting machine is suitable for the washing and selecting, granding, and trash-extracting in industries like metallurgy, construction, water and electricity, etc. This series is suitable for washing and selecting materials of fine and rough granularity.

Working principle of Screw Sand Washing machine:

The motor and reducer drive the impeller to slowly rotate. Materials enter the machine through the feedertrough, and are separated from the soil and impurities covered on the sand surface due to the function of propulsion, mixing and water flow. The clean fine sand is poured into the discharge chute under the propulsion of spiral, and the soil and impurities are discharged from the overflow port under the effect of water flow.

Characteristics of Screw Sand Washing machine:

-High level cleaning; reasonable structure

-Big treatment amounts; small power dissipation
-Small loss of sand during the process of sand washing.

-Much lower malfunction rate than sand washing machine used commonly at present.

Main technical paramete of screw sand washing machine:

Model	Spiral diameter (mm)	Capacity(t/h)	Power	Weight(kg)
XSL-50	500	12-20	3	2550
XSL-75	750	40-55	5.5	3820
XSL-100	1000	60-75	7.5	4870
XSL-120	1200	80-100	11	6900
XSL-150	1500	100-130	18.5	8800
XSL-200	2000	130-160	22	19000
2XSL-100	1000	120-150	7.5×2	8900
2XSL-120	1200	160-200	11×2	13100

Welcome to China and welcome to visit Yufeng, if you have any other questions, you may contact with us, we will spply you the highest service as soon as quickly. Marcie Liu, Mobile:18236781826
