china brand shotcrete machine

china brand shotcrete machine, 1.wet mix and dry mix shotcrete, 2.sealing plate and rotor disk duration - details see: https://www.machineto.com/china-brand-shotcrete-machine-10095727

Place of Origin:Henan China (Mainland)	Brand Name:RISEN	Model Number:PZS3000	Colour:customized colour
Port:Shanghai, Qingdao, Tianjin	way of driven:electric driven	market:global market	technology:advanced
way of mix:dry and wet	convey dis.:35m/200m	operation air pressure:0.2---0.6Mpa	weight:1200kg

The RISEN PZS3000 has the dvanced concrete spraying technique, developed from our PZ series dry-mix shotcrete and incorporated the advantages of wet-mix shotcrete. Today, it is a universal concrete spraying machine for the processing of wet or dry mix.

Technical Data:

Output	5 CBM/h(wet material)	8—9CBM/h(dry material)
Max.convey dist.	35 m	200m
Max.aggregate size	φ15 mm	φ15 mm
Concrete slump	8-15 cm
Hose inner size	φ50/65 mm	φ50/65 mm
Operating air pressure	0.2-0.6 MPa	0.2-0.6 MPa
Air consumption	9-10 /min	9-10 /min
Discharge height	1.17 m	1.17 m
Rotor Rev.	11 r/min	11 r/min
Main electric motor power	7.5 kW	7.5 kW
Dosing pupmp model	BRJ15
Dosing pump rated pressure	0.6 MPa
Dosing pump output	17.5-88 L/h
Overall dimension	2050×950×1180 mm	2050×950×1180 mm
weight	1200 kg	1200 kg

Application:

Shotcreting for tunnels, hydro-power engineering, mines, underground engineering, civil engineering and slope stabilization, etc.
Artificial soil seeding for no soil surface, such as rock, sand, and for no fertility soil surface.
Refractory spraying and repair for industrial kilns or kilns’ inner liner.

Features:

Going-through rotor and forced vibrating hopper make mixture smoothly falling.
Hose dosing pump unit provides constant dosing.
Thin flow conveying method, used for wet-mix and dry-mix shotcrete.
Reinforced shotcrete with steel or various polyment fibre. For the most specific risks of this machine, safety and compliance with the essential requirements of the Directive has been based on elements of EN ISO 12100-1:2003, EN ISO 12100-2:2003/A1:1995, EN 60204-1:2006 and EN 1050:1997
