1.change the molds, different tiles 2.efficient, water-proof,high strength and density,wear-resisting 3.elegent appearance 4nice - details see: https://www.machineto.com/cement-color-roof-tile-machine-production-line-10086163

Roof Tile Making Machine

No.1 MYWJ-125 model Tile Making Machine adopts multiple advanced technology.

1.A tractor serves several purposes,large-tonnage,low power consumption,compression molding by numerical control.

MYWJ 125 has excellent product design,multifunction shaped by fluid pressure,human interface ,advanced arrangement,which supply the gap of domestic.The finished goods are featured by high density,high strength,wide in variety,and the machine can produce many kinds of high-quality tiles which are the competitive products of the concrete products by changing the mold,

2.MYWJ 125 adopt the best configuration which is imported with original packaging.

It adopt the original mixing together with PC, mechanical, electrical, hydraulic and gas technique.Full automatic control,the overall system is more reliable and stable,the production and finished product ratio are higher and exceed the level of similar products imported from abroad.

3.Technical innovation,long-distance diagnose.

With more than 20 years rich experience accumulation and the large numbers of users' feedback,the specific details of our machine are gradually improved.The latest machine has the long-distance diagnose system,our engineer can do data analysis to the user's machine in the farthese place,which is very convenient for the users to do the machine maintenance.

4.Small investment,fast speed,high capacity.

With high content of technology,fast speed,high capacity(the output per day can increase about 80%).And the product has good benifit and bright market prospect.

No.2 The Consist of Machine

1.Moulding Tile Forming Machine

2.Wheel Agitator

3.Automatic Weighing and Feeding Machine

4.Bucket Elevator

No.3 Process Flow

1.Preparing the raw material

Cement 1.5 Medium Sand 2.0 Coal Ash 0.5

2. Bucket Elevator

3.Wheel Agitator

4.Automatic Weighing and Feeding Machine

5.Curing Pallet

6.Hand Fork Lifter

7.Coating Line

8.Finished Goods

No.4 Features of Encaustic Cement Tile

1.Unique Water-proof Structure

Only the moulding tile have the valley bottom structure,which is very useful for the discharge of the rain,and can be effectively to avoided the reflux of the rain.What's more,the higher part of the tile's head can never make the reflux of the rain,even on the horizontal roofing.

2.Superhigh Strength

The tile produced by MYWJ 125 has superhigh strength,about 1250 KN,and the overall dimension is very accurate(425mm×337mm,about 9 pcs/m²).The density is very homogeneous,the rupture strength is more than 200 KG,which can bear the constructor's weight easily.

3.Convenient Construction

4.Superhigh Wind Resistance

5.Good Heat-shielding Performance

6.Good Resistance to Freezing and Thawing

7.Good Impermeability

8.Low-cost, high-yielding.

No.5 Technological Parameter

Model	MYWJ-125
Overall Dimension	3120×1750×2650 mm
Moulding Cycle	8-10 s
Moulding Pressure	1250 KN
Weight of Main Engine	5.5 T
Equipped Capacitor	5.5 kw
Production Capacity	3800-4000 pcs/day
Tile Size	424×377×10 mm
