2013-2013 New Energy Saving Wet Grinding Ball Mill, Dry Grinding Ball Mill with Low Price

Energy saving wet grinding Ball Mill, 1.Mn liner, Rubber liner, Ceramic liner, 2.whole base support, easy to installation - details see: https://www.machineto.com/2013-2013-new-energy-saving-wet-grinding-ball-mill-dry-grinding-ball-mill-with-low-price-10314614
Condition:NewType:Ball MillMotor Type:AC MotorPower(W):210kw
Capacity(t/h):0.4-180t/hPlace of Origin:Henan China (Mainland)Brand Name:DHModel Number:multi-type
Certification:ISO9001/2008Warranty:1 yearAfter-sales Service Provided:Engineers available to service machinery overseasGuarantee:1 year
Application:Gold ore, Iron ore, stone, Rock , Coconut shell, Silica sandetcEfficient:high capacity and finenessQuality:ISO9001:2008 approvedConsumption:reduced by 30%
Constructure:simple and firmTraining:free guideInstallation:under the engineer's guideMaintenance:convenient
Price:Competitive
2013-2013 New Energy Saving Wet Grinding Ball Mill, Dry Grinding Ball Mill with Low Price
contact supplier for 2013-2013 New Energy Saving Wet Grinding Ball Mill, Dry Grinding Ball Mill with Low Price


Zhengzhou Dahua Brand Energy Saving Dry and Wet grinding Ball Millis widely used for Gold Ore grinding, Copper Ore grinding, Iron Ore grinding, Silica sand grinding, Ceramic grinding, Limestone grinding, Raw & clinker cement, Slag, Pig Iron, Soil, Brick, Etc

1.simple structure ball mill
2.reduced consumption by 30%
3.increased capacity by 20%
4.Improve fineness

Energy saving wet grinding Ball millfrom Zhenghzou Dahua have passed the ISO9001:2008 quaility certification with good after sales service.
So far, Zhengzhou Dahua have exported many kinds ore dressing such as Crushers, ball mill, flotation machine, Drying equipment, etc. , Which is often used in gold ore, iron ore, copper ore, chrome ore, Al ore, etc. from 0.5t/h to 180t/h. Welcome your enquiry.The free design will be send you soon to promote our business.
Energy Saving wet grinding Ball Mill Introduction:

Wet Ball Mill is a key tool for grinding many materials into fine powder. There are two ways of grinding: the dry way and the wet way. It can be divided into tabular type and flowing type according to different expelling mine.Quite simply, the longer the ball mill runs, the finer the powder will be. Ultimate particle size depends entirely on how hard the material you're grinding is, and the time how long the ball mill runs. This product is widely used to make all kinds of mine, such as cement, fire-proof materials, aluminum soil, the emery, glass raw materials, building sand, stone materials, metallurgical slag.

Welcome to your order.
Energy Saving wet grinding Ball Mill Application :

Wet Ball Mill is an efficient tool for grinding many materials into fine powder. The wet ball mill is used to grind many kinds of mine and other materials, or to select the mine. It is widely used in building material, chemical industry, etc. such as cement, fire-proof materials, aluminum soil, the emery, glass raw materials, building sand, stone materials, metallurgical slag.

Energy Saving wet grinding Ball Mill Features:

1. High capacity and Low consumption: the capacity of SCM series super-micro mill, compared with that of jet mill and mixing mill, has been improved by 40% under the same final fineness and electric power.

2. High fineness and Flexible adjustment: the final fineness can be adjusted from 20 meshes to 325 meshes according to the requirements, and the fineness can reach 47um.

3. Trustworthy security: there is no rolling bearing and bolt in the mill chamber, therefore, the bearing and sealing elements will not wear out easily, and the bolts will not loose to make damage to the equipment.

4. Clean and environment-friendly: equipped with the pulse filter and sound absorber, the mill reaches the environment-friendly standard of our country and reduces the dust and noise greatly.

Working Principle of Energy Saving we ginding Ball Mill
The wet ball mill is a horizontal rotating device transmitted by the outer gear. The materials are transferred to the grinding chamber through the quill shaft uniformly. There are ladder liner and ripple liner and different specifications of steel balls in the chamber. The centrifugal force caused by rotation of barrel brings the steel balls to a certain height and impact and grind the materials. The ground materials are discharged through the discharging board thus the grinding process is finished.

wet grinding Ball Mill Machine main parameter:

ModelCylinder rotary speed(r/min)Loading ball weight(t)Input size(mm)Discharge size(mm)Capacity(t/h)Motor power (kw)Weight (t)
Ø900×1800391.5≤200.075-0.890.8-218.54.6
Ø900×3000392.7≤200.075-0.891~4225.6
Ø1200×4500325≤250.074-0.41.6-5.85513.8
Ø1500×3000277.5≤250.074-0.42~57515.6
Ø1500×57002812≤250.074-0.43.5-613024.7
Ø1830×30002511≤250.074-0.44~1013028
Ø1830×64002421≤250.074-0.47~1621034
Ø2100×36002319≤250.074-0.410-3621046
Ø2200×45002127≤250.074-0.412~2328048.5
Ø2200×65002135≤250.074-0.414-2638052.8
Ø2200×70002135≤250.074-0.415-2838054
Ø2200×75002135≤250.074-0.415-3038056
Ø2400×45002130≤250.074-0.418-4532065
Ø2700×36002139≤250.074-0.419-7540083
Ø2700×45002048≤250.074-0.422-8543089
Ø3200×45001865≤250.074-0.429-140800137
Ø3200×54001881.6≤250.074-0.430-180800-1000146
Ø3600×45001788≤250.074-0.435-2101000190
Ø3600×850017144≤250.074-0.445-2601800260
There is inventory, welcome yo your first order. Of course , welcome to visit our factory and workshop.
2013-2013 New Energy Saving Wet Grinding Ball Mill, Dry Grinding Ball Mill with Low Price
Packaging Detail:standard packing or as your request
Delivery Detail:in 15 days after receiving the deposit
