2011 best sale diesel concrete vibrator
diesel concrete vibrator, 1,safe to portble use, 2,consolidate cement, 3,transmitted by flexible shaft,speed increased - details see: https://www.machineto.com/2011-best-sale-diesel-concrete-vibrator-10095086
| Place of Origin:Henan China (Mainland) | Brand Name:NMB | Model Number:NMB | Type:Internal |
| Drive Mode:Electric Vibrator | Frequency:250HZ | Vibrating Amplitude:0.5-1.45MM | Length of Flexible Shaft:see the bellow for details |
| power:380V/50HZ/3phase |
diesel concrete vibrator
The concrete vibrator is used to consolidate cement andremove all the trapped air bubblesto give you the toughest cement possible.It is transmitted by flexible shaft,speed increased through planet structure,then gainhigh frequent vibration.
Technical Data
| Vibration freq(Hz) | max,amplitude ofunloaded vibration(mm) | productivity (m3/h) | dia.of poker (mm) | flexible shaft dia.(mm) | hose dia (mm) | revolution (r/mm) | input power (KW) | power supply | total weight (kg) | |
| NMB25 | 250 | 0.5 | 3 | 26 | 8 | 24 | 2850 | 1.3 | 3 | 20 |
| NMB 35 | 225 | 0.8 | 7 | 36 | 10 | 30 | 2850 | 1.3 | 21 | |
| NMB 42 | 210 | 1.08 | 7.5 | 44 | 10 | 30 | 2850 | 1.3 | 25 | |
| NMB 50 | 200 | 1.15 | 13 | 51 | 13 | 36 | 2850 | 1.3 | 29 | |
| NMB 50C | 200 | 1.15 | 13 | 51 | 13 | 36/46 | 2850 | 1.3 | 34 | |
| NMB 70G | 200 | 1.35 | 23 | 68 | 13 | 36/46 | 2850 | 1.8 | 41 | |
| NMB 100 | 150 | 1.45 | 102 | 13 | 2850 | 1.8 | 67 | |||
| NMB Co | 200 | 1.15 | 13 | 51 | 13 | 36 | 2850/3450 | 1.8 | 220V / 50Hz |
| Packaging Detail:wood box |
| Delivery Detail:10 days |
