16 ton Electric Wire Rope hoist and lift with CE,No.1 in China for 7years

16 ton Wire Rope Electric Hoist, Capacity:5 ton, Widely used in various industries, Strong,durable, popular - details see: https://www.machineto.com/16-ton-electric-wire-rope-hoist-and-lift-with-ce-no-1-in-china-for-7years-10096984

Condition:New	Place of Origin:Henan China (Mainland)	Brand Name:KUANGYUAN	Model Number:CD
Usage:Construction Hoist	Power Source:Electric	Sling Type:Wire Rope	Maximum Lifting Weight:20 ton
Maximum Lifting Height:48m	Lift Speed:8m/min	Certification:ISO CE	Warranty:12 month
After-sales Service Provided:Engineers available to service machinery overseas	GB/T 24001-2004 idt ISO14001:2004:Pass	GB/T 19001-2000 idt ISO 9001:2000:Pass	GB/T 28001-2001,OHSAS18001:1999:Pass
SGS certificates:Pass	Mechanism:M3	Motor:Nanjing or Nanjing special motor	Main electrical parts:Siemens or CHINT brand
Current overload protection system:Include	Weight overload protection function:Include	Frequency inverter:Could supply

16 ton Electric Wire Rope hoist and lift with CE,No.1 in China for 7years

contact supplier for 16 ton Electric Wire Rope hoist and lift with CE,No.1 in China for 7years

(No.1 in China for 7years) 16 ton Electric Wire Rope Hoists lift and hoist hoist and lift

16 ton Wire Rope hoist Introduction:

16 ton Wire Rope Hoist

Absolute reliability is one of the most important features for a 16 ton wire rope hoist. To ensure the highest

possible reliability levels in day-today operation, our crane systems are made to the most stringent quality standards. Kuangyuan electric wire rope hoists are produced using the most advanced technology available and continue to bear witness to their reliability, safety

and durability year after year, from motor to rope, gearbox, brakes and electrical and electronic systems.

Wire rope hoist made by Henan Mine Crane Co.,Ltd, Famous Brand in China-Kuangyuan. Winnig customers' high compliment and recognition.

Technical specification:

Model		CD
Capacity		Ton	0.5	1	2	3	5	10	16
Hoisting height		M	6,9,12	6,9,12,18,24,30				9,12,18,24,30
Hoisting speed		M/MIN	8	8				7	3.5
Travel speed		M/MIN	20/30	20/30	20/30	20/30	20/30	20/30	18
Wirerope		Dia.(mm)	4.8	7.4	11	13	15	15	17.5
Wirerope		Spec.	6x37+FC	6x37+FC
Hoisting motor	Type	Type	ZD121-4	ZD122-4	ZD131-4	ZD132-4	ZD141-4	ZD151-4	ZD151-4
	Power	Power(kW)	0.8	1.5	3	4.5	7.5	13	13
	Rotation speed	Rotation speed(r/min)	1380	1380	1380	1380	1400	1400	1400
	Current		2.2	4.3	7.6	11	18	30	30
Travel motor	Type	Type	ZDY111-4	ZDY111-4	ZDY112-4	ZDY112-4	ZDY121-4	ZDY121-4	ZDY121-4
	Power	Power(kW)	0.2	0.2	0.4	0.4	0.8	0.8x2	0.8x2
	Rotation speed	Rotation speed(r/min)	1380	1380	1380	1380	1380	1380	1380
	Current	Current(A)	0.72	0.72	1.25	1.25	2.4	2.4	2.4
Power		3P AC/380v/400v/415v/440v380V,50HZ/60HZ,

Variable Types of Electric Hoist:

* Frequency inversion functional electric hoist;

* CD1 model wire rope electric hoist;

* Sound & light alarm functioning electric hoist;

* Curve travelling electric hoist;

* Pendant pushbutton with remote control functional electric hoist;

* Overload limiter functional electric hoist;

* Low headroom electric hoist

* Casting, foudry, ladle use wire rope electric hoist;

* Explosion-proof electric hoist;

Introduction:

Features

Salient

Manufactured as per IS : 3938 & 807

100% Steel Fabricated

ElPrecision Machine Cut Alloy Steel Gears

Helical Gears

Rope Drum - Out of Seamless Pipe

Best Electrical Components

Swivelling Snatch Block

Adjustable Mounting

Long Lasting Life

Optional

Unconditional Warranty

Variable Speed Variant

Special Applications

Soft Start & Stop

Gravity Type Emergency Limit Switch

Intelligent Panel

Flame Proof

Rope Guide

Rust Proof

Safety

2 Falls Wire Rope

Emergency Stop

Overload Tripping

Limit Switch

About us:

Henan Mine Crane Co.,Ltd, the No.1 crane manufacturer in China Crane Hometown, the earliest and professional company to open oversea market. In 2012, our group achieved the total sales performance of 400 million US dollars. We have the China famous “Kuangyuan” brand of electric hoist, overhead crane, gantry crane, metallurgy crane, anti-explosion crane and related pare parts. The factory and products have been verified by ISO, OHSAS standard, SGS, GOST and CE authorities. We have 2700 employees including 180 middle and senior class technicians and engineers to design and manufacture the best crane for customers. The factory covers 680,000 square meters and has over 380 agencies. To control the crane quality, we have unique advanced production line such as large scale CNC center, wheel casting, crane wheel medium-frequency quenching, crane beam one time forming production line, sand blast line, ultrasonic inspection device, X-ray flaw detector and 600 ton crane test station, etc. so we can ensure to supply you the best quality crane. We have received a range of awards Advanced Technology Enterprise, China Famous Brand, China TOP 10 Crane Brand, Quality Management Qualified Enterprise, and Reliable Quality Enterprise-more than 120 honors in total. We have the most professional sale, installation, service team and the richest exporting experience. Our products has been exported to German, America, Australia, South Africa, Thailand, Pakistan, Mexico, Brazil, Kenya, and more than 65 countries over the world. Henan Mine Crane Co.,Ltd sincerely welcome your visit and hope to achieve a win-win cooperation with each other!

Factory View: 680,000m²and 3300 employees- Biggest in China, welcome your visit!

Shipping

Payment

1. L/C

2.T/T

Certification(CE & GOST)

Customer Visit:

Our service\Buyer Guidelines
Our strongest point is that we consult. So anything you want to know about cranes adn hoist, please ask us!
